Dry alarm valve ZSFC100-150

ZSFC100-150

Retail price

Market price

Weight

Quantity

Stock

隐藏域元素占位

Classification:

Key words:

Dry alarm valve

Product Description

Commodity name: Dry alarm valve ZSFC100-150
Commodity ID: ZSFC100-150

1. model preparation:

Example: ZSFC100 represents a dry alarm valve with a nominal diameter of 100mm and a nominal pressure of 1.6MPa

2. executive standard: GB5135.5-2003 "automatic sprinkler system part 4: dry alarm valve"

3. technical parameters:

Model specifications	Nominal diameter （mm）	Nominal working pressure (MPa)	Water supply pressure range (MPa)	Alarm port pressure (MPa)	Environmental conditions for system use
ZSFC100	100	1.6	0.14～1.6	≥ 0.05	<4 ℃ or> 70 ℃
ZSFC150	150	1.6	0.14～1.6	≥ 0.05	<4 ℃ or> 70 ℃

4. applicable places: used in hospitals, hotels, shopping malls, factories, warehouses, airports, casinos, libraries, stadiums, convention and exhibition centers and other automatic sprinkler systems.

1. model preparation:

Example: ZSFC100 represents a dry alarm valve with a nominal diameter of 100mm and a nominal pressure of 1.6MPa

2. executive standard: GB5135.5-2003 "automatic sprinkler system part 4: dry alarm valve"

3. technical parameters:

Model specifications	Nominal diameter （mm）	Nominal working pressure (MPa)	Water supply pressure range (MPa)	Alarm port pressure (MPa)	Environmental conditions for system use
ZSFC100	100	1.6	0.14～1.6	≥ 0.05	<4 ℃ or> 70 ℃
ZSFC150	150	1.6	0.14～1.6	≥ 0.05	<4 ℃ or> 70 ℃
